Air Container
M-1 AMA RECTANGULAR CONTAINER ON P6P BASE
IATA ULD code:AMA rectangular container on P6P base
Prefixes:AMF, AMG, AMK, AMP, AQA, AQD, and AQ6
Rate class:Type 2
Description:Main-deck container. Door is canvas with built-in net door straps.
Suitable for:747F, 747 Combi, 777F center loading only
Maximum gross weight:6,804 cm (15,000 lb).
Tare weight:350 kg (772 lb),
AS1825 volume:17.6 m3 (623 ft3)
M1H - AMD CONTOURED
IATA ULD code:AMD contoured
Prefixes:AQD, AMD
Rate class:Type 2H
Description:Main-deck upper contoured container. Door is canvas with built-in net door straps.
Suitable for:747F, 747 Combi777F center loading only
Maximum gross weight:6,800 kg (14,491 lb)
AS1825 volume:21.2 m3 (750 ft3)
PMC/P6P 10-FT FLAT PALLET WITH NET
IATA ULD code:P6P 10-ft flat pallet with net
Rate class:Type 2BG
Description:Universal general-purpose flat pallet for lower holds and main decks.
Suitable for:747, 767, 777, 787, DC-10, MD-11
Tare weight:120 kg (265 lb)
AS1825 volume:H 162.6 cm H 243.8 cm H 299.7 cm H 162.2 cm H 243.8 cm H 299.7 cm
Boeing volume:(64 in), 11.5 m3 (407 ft3) (96 in), 17.0 m3 (600 ft3) (118 in), 21.2 m3 (750 ft3) (64 in), 11.7 m3 (415 ft3) (96 in), 17.0 m3 (600 ft3) (118 in), 21.2 m3 (750 ft3)
LD-7 P1P FLAT PALLET WITH NET
IATA ULD code:P1P flat pallet with net
Prefixes:PAA, PAG, PAJ, PAP, PAX, P1A, P1C, P1D, and P1G
Rate class: Type 5
Description:Universal general-purpose flat pallet for lower holds and main decks.
Suitable for:
Widebody:All aircraft lower holds and main decks
Standard-body:707F, 727F, 737F, 757F, DC8F, DC9F main decks
Maximum gross weight:4,626 kg (10,198 lb)
Tare weight:105 kg (231 lb)
AS1825 volume:10.5 m3 (370 ft3)
Boeing volume:10.7 m3 (379 ft3)
LD-9 AAP ENCLOSED PALLET ON P1P BASE
IATA ULD code:AAP enclosed pallet on P1P base
Rate class:Type 5
Description:General-purpose enclosed container fitted to P1P base. Door is canvas with built-in net door straps, or solid.
Suitable for:747, 767, 777, 787, DC-10, MD-11 lower hold
Door opening:118 x 58 in (300 x 147-cm)
Maximum gross weight:Lower hold, 4,624 kg (10,194 lb); main deck, 6,000 kg (13,227 lb)
Tare weight:Canvas door, 215 kg (473 lb); solid door, 270 kg (595 lb)
AS1825 volume:10.8 m3 (381 ft3)
Boeing volume:10.8 m3(381 ft3)
LD-29 AAU CONTOURED CONTAINER ON P1P BASE
IATA ULD code:AAU contoured container on P1P base
Rate class:Type 5
Description: Full-width lower hold container angled at both ends. Door is canvas with built-in net door straps.
Suitable for:747 lower hold Door opening: 118 x 60-in (300 x 152-cm).
Maximum gross weight:6,033 kg (13,300 lb)
Tare weight:265 kg (584 lb)
AS1825 volume:14.4 m3 (510 ft3)
LD-8 DQF
IATA ULD code:DQF
Prefixes:ALE, ALN, DLE, DLF, DQP, and MQP
Rate class:Type 6A
Description:Full-width lower hold container angled at both ends. Door is canvas with built-in door straps.
Suitable for:767, 787 lower hold
Door opening: 92 x 62-in (234 x 157-cm)
Maximum gross weight:2,450 kg (5,401 lb)
Tare weight:127 kg (280 lb)
AS1825 volume:7.1 m3(252 ft3)
Boeing volume:6.9 m3 (245 ft3)
LD-3 AKE CONTOURED CONTAINER
IATA ULD code:AKE contoured container
Prefixes:AKE, AVA, AVB, AVC, AVK, DVA, DVE, DVP, XKS, XKG, and forkable AKN, AVN, DKN, DVN, and XKN
Rate class:Type 8
Description:Half-width lower deck container with one angled side. Door is either canvas or solid.
Door opening: 58 x 61 in (147 x 155 cm)
Tare weight:181 lb (82 kg)
AS1825 volume:159 ft3 (4.5 m3)
LD-1 AKC CONTOURED CONTAINER
IATA ULD code:AKC contoured container
Prefixes:AVC, AVD, AVK, AVJ, and forkable AVY
Rate class:Type 8
Description:Half-width lower hold container with one angled side. Door is either canvas or solid.
Loadability:747, 767, 777, 787, MD-11 lower hold
Door opening:147 x 155 cm (58 x 61 in)
Maximum gross weight:1,588 kg (3,501 lb)
Tare weight:70 to 170 kg (155 to 375 lb)
AS1825 volume:5.0 m3(175 ft3)
