SEA CONTAINER
45' HIGH CUBE CONTAINER
Interior Dimensions:L: 13.582 m 44' 6 1/2"W: 2.347 m 7'8.25"H: 2.690 m 8'10"
Door Opening:W: 2.347 m 7'8 1/4"H: 2.584 m 8'5 3/4"
Top Opening:
Tare Weight:4,110 kg 9,061 lbs.
Cubic Capacity:85.7 cbm.3,026 cu. ft.
Payload:28,390 kg 62,589 lbs.
40' HIGH CUBE CONTAINER
Interior Dimensions:L: 12.056 m 39' 6 1/2" W: 2.347 m 7'8 1/4" H: 2.684 m 8'9 1/2"
Door Opening:W: 2.340 m 7'8" H: 2.585 m 8'5 3/4"
Top Opening:
Tare Weight:2,900 kg 6,393 lbs.
Cubic Capacity:76.0 cbm. 2,684 cu. ft.
Payload:29,600 kg 65,256 lbs.
40' DRY FREIGHT CONTAINER
Interior Dimensions:L: 12.051 m 39' 6 1/2" W: 2.340 m 7'8" H: 2.380 m 7'9 1/2"
Door Opening:W: 2.286 m 7'6" H: 2.278 m 7'5 1/2"
Top Opening:
Tare Weight:3,084 kg 6,799 lbs. 3,630 kg (steel) 8,003 lbs. (steel)
Cubic Capacity:67.3 cbm. 2,377 cu. ft.
Payload:27,397 kg 60,401 lbs.
20' DRY FREIGHT CONTAINER
Interior Dimensions:L: 5.919 m 19' 5" W: 2.340 m 7'8" H: 2.380 m 7'9 1/2"
Door Opening:W: 2.286 m 7'6" H: 2.278 m 7'5 1/2"
Top Opening:
Tare Weight:1,900 kg 4,189 lbs.
Cubic Capacity:33.0 cbm. 1,165 cu. ft.
Payload:22,100 kg 48,721 lbs.
20' OPEN TOP CONTAINER
Interior Dimensions:L: 5.919 m 19' 5" W: 2.340 m 7'8" H: 2.380 m 7'9 1/2"
Door Opening:W: 2.286 m 7'6" H: 2.251 m 7'4 1/2"
Top Opening:L: 5.425 m 17'9 1/2" W: 2.222 m 7'3 1/2"
Tare Weight:2,174 kg 4,793 lbs.
Cubic Capacity:31.6 cbm. 1,116 cu. ft.
Payload:21,826 kg 48,117 lbs.
40' OPEN TOP CONTAINER
Interior Dimensions:L: 12.043 m 39' 6" W: 2.338 m 7'8" H: 2.272 m 7'5 1/4"
Door Opening:W: 2.279 m 7'5 1/2" H: 2.272 m 7'5 1/4"
Top Opening:L: 11.585 m 38' W: 2.162 m 7'1"
Tare Weight:4,300 kg 9,480 lbs.
Cubic Capacity:64.0 cbm. 2,260 cu. ft.
Payload:26,181 kg 57,720 lbs.
45' HIGH CUBE REEFER CONTAINER
Interior Dimensions:L: 13.102 m 42'11 13/16" W: 2.294 m 7'6 5/16" H: 2.509 m 8'2 3/4"
Door Opening:W: 2.467 m 8'1 1/8" H: 2.290 m 7'6 1/8"
Top Opening:
Tare Weight:5,200 kg 11,464 lbs.
Cubic Capacity:75.4 cbm. 2,663 cu. ft.
Payload:28,350 kg 62,370 lbs.
40' HIGH CUBE REEFER CONTAINER
Interior Dimensions:L: 11.557 m 37'11" W: 2.286 m 7'6" H: 2.491 m 8'2"
Door Opening:W: 2.286 m 7'6" H: 2.454 m 8'1/2"
Top Opening:
Tare Weight:4,320 kg 9,524 lbs.
Cubic Capacity:65.8 cbm. 2,324 cu. ft.
Payload:28,180 kg 62,126 lbs.
40' REEFER CONTAINER
Interior Dimensions:L: 11.207 m 36'9" W: 2.246 m 7'4" H: 2.183 m 7'2"
Door Opening:W: 2.216 m 7'3" H: 2.183 m 7'2"
Top Opening:
Tare Weight:4,600 kg 10,141 lbs.
Cubic Capacity:54.9 cbm. 1,940 cu. ft.
Payload:25,881 kg 57,059 lbs.
20' FLAT RACK CONTAINER
Interior Dimensions:L: 5.702 m 18'8 1/2" W: 2.438 m 8' H: 2.327 m 7'7 1/2"
Door Opening:
Top Opening:
Tare Weight:2,330 kg 5,137 lbs.
Cubic Capacity:
Payload:21,670 kg 47,773 lbs.
40' FLAT RACK CONTAINER
Interior Dimensions:L: 11.820 m 38'9 1/4" W: 2.148 m 7'6" H: 2.095 m 6'10 1/2"
Door Opening:
Top Opening:
Tare Weight:5,260 kg 11,596 lbs.
Cubic Capacity:
Payload:25,220 kg 55,660 lbs.
